Air 2000 is a conveyorized PCB Dryer. Adjustable transport speed ensures perfect drying of holes and surfaces at the end of all wet process sequences.
Features:
- Continuous drying
- Variable transport speed
- Suitable for different board thicknesses
- Low surface temperature
- Short heating-up time
- High throughput
- Bench top machine
- High quality construction
|
|
Technical Data:
- Working width: 300 mm
- Board thickness: 0.2 - 4 mm
- Minimum board length: 80 mm
- Transport speed: 0.2 - 1,2 m/min
- Heat up time: 5 sec.
- Dimensions (WxDxH): 352 x 520 x 362 mm
- Power supply: 230 V 50Hz
|
